Exposure Mono Amplifier 5010, Titanium, 2Pcs

Features • Large custom made toroidal power transformer and multiple smoothing capacitors for power supply • Option to fit a MC or MM phono module OR plug in DAC option • 6 line inputs or 5 plus optional phono card, 2 main out (RCA), 1 XLR main out and 1 tape output • High quality relays used for input source selection • Full remote control of input selector, volume and mute • Audio output stages utilising discrete transistor class A output buffer • Balanced pre-amp output, DC coupled • High quality all aluminium case work • Remote control • Three year guarantee • Available in black or titanium Specifications Outputs Gain (at 1kHz) : 9dB unbalanced output 15dB balanced output Sensitivity : 500mV Maximum Output : >9V RMS unbalanced Frequency Response : -3dB at 1Hz and 57kHz, ref 1kHz, max volume Total Harmonic Distortion : <0.005% at 1.6V RMS output, 1kHz Signal to Noise Ratio : >98dB, A weighted, ref 1.6V RMS output, 1kHz Channel Separation : >60dB 20Hz to 20kHz (Typically >85dB at 1kHz) Outputs : 2 pairs RCA, pre-amp output, 1 pair for tape output Inputs Input Impedance : 18K Ohms minimum General Mains Supply : 110/120V or 220/240V, 50/60Hz (factory set) Fuse : T5AL for 110/120V units T2.5AL for 220/240V units Power Consumption : <25W Dimensions (HxWxD) : 90mm x 440mm x 300mm Net Weight : 6kg Gross Weight : 8kg Package Contents: Exposure Mono Amplifier 5010, Titanium, 2Pcs; Power cable, Manual.
